Allen-Bradley 1336 FORCE User Manual

Chapter 5
Programming Parameters
5–32
Drive Link Receive 2 Address
[D2D Rcv 2 Addr]
Parameter Number 13
Parameter Type Sink
Display Units x
Drive Units None
Factory Default 0
Minimum Value 0
Maximum Value 64
Drive Link Transmit Indirect 1
[D2D Xmit Ind 1]
Drive Link Transmit Indirect 2
[D2D Xmit Ind 2]
Parameter Number 15
Parameter Type Sink
Display Units x
Drive Units None
Factory Default 21
Minimum Value 1
Maximum Value 219
Parameter Number 14
Parameter Type Sink
Display Units x
Drive Units None
Factory Default 20
Minimum Value 1
Maximum Value 219
This is a word parameter defining the pa-
rameter number which data will be fetched
from to be transmitted in the high speed
communication network (CAN) for the first
word location of the transmitted message.
This is a word parameter defining the pa-
rameter number which data will be fetched
from to be transmitted in the high speed
communication network (CAN) for the 2nd
word location of the transmitted message.
This parameter specifies the node address
at which two words of data will be
received. A value of zero disables the
receive function.
Drive Link Receive 1, Indirect 1
[D2D Rcv 1, Ind 1]
Parameter Number 16
Parameter Type Sink
Display Units x
Drive Units None
Factory Default 22
Minimum Value 1
Maximum Value 219
Drive Link Receive 1, Indirect 2
[D2D Rcv 1, Ind 2]
Parameter Number 17
Parameter Type Sink
Display Units x
Drive Units None
Factory Default 23
Minimum Value 1
Maximum Value 219
Drive Link Receive 2, Indirect 1
[D2D Rcv 2, Ind 1]
Drive Link Receive 2, Indirect 2
[D2D Rcv 2, Ind 2]
Parameter Number 19
Parameter Type Sink
Display Units x
Drive Units None
Factory Default 25
Minimum Value 1
Maximum Value 219
Parameter Number 18
Parameter Type Sink
Display Units x
Drive Units None
Factory Default 24
Minimum Value 1
Maximum Value 219
This parameter specifies the parameter
number where the first word of data will be
put after it has been received from the
drive to drive communication.
This parameter specifies the parameter
number where the second word of data will
be put after it has been received from the
drive to drive communication.
This parameter specifies the parameter
number where the first word of data will be
put after it has been received from the
drive to drive communication.
This parameter specifies the parameter
number where the second word of data will
be put after it has been received from the
drive to drive communication.
