Allen-Bradley 1336 FORCE User Manual

Chapter 5
Programming Parameters
5–33
Drive Link Transmit Data 1
[D2D Xmit Data1]
Parameter Number 20
Parameter Type Sink
Display Units +/– x
Drive Units None
Factory Default 0
Minimum Value –32767
Maximum Value +32767
Drive Link Transmit Data 2
[D2D Xmit Data2]
Drive Link Receive 1, Data 1
[D2D Rcv 1, Data1]
Parameter Number 22
Parameter Type Source
Display Units +/– x
Drive Units None
Factory Default 0
Minimum Value –32767
Maximum Value 32767
Parameter Number 21
Parameter Type Sink
Display Units +/– x
Drive Units None
Factory Default 0
Minimum Value –32767
Maximum Value 32767
This parameter is the default data location
of the first word of data for transmit.
This parameter is the default data location
of the second word of data for transmit.
This parameter is the default data location
of the first word of data for receive 1
Drive Link Receive 1, Data 2
[D2D Rcv 1, Data 2]
Parameter Number 23
Parameter Type Source
Display Units +/– x
Drive Units None
Factory Default 0
Minimum Value –32767
Maximum Value 32767
Drive Link Receive 2, Data 1
[D2D Rcv 2, Data 1]
Parameter Number 24
Parameter Type Source
Display Units +/– x
Drive Units None
Factory Default 0
Minimum Value –32767
Maximum Value 32767
Drive Link Receive 2, Data 2
[D2D Rcv 2, Data 2]
Parameter Number 25
Parameter Type Source
Display Units +/– x
Drive Units None
Factory Default 0
Minimum Value –32767
Maximum Value 32767
This parameter is the default data location
of the second word of data for receive 1
This parameter is the default data location
of the first word of data for receive 2
This parameter is the default data location
of the second word of data for receive 2
Process Trim Output
[Proc Trim Output]
Parameter Number 26
Parameter Type Source
Display Units +/– x.x%
Drive Units 4096 = 100% trim
Factory Default + 0.0%
Minimum Value – 800.0%
Maximum Value + 800.0%
This parameter represents the scaled and
limited output of the process trim
function. Process Trim consists of a
general purpose PI regulator that uses
unspecified reference and feedback inputs.
