Allen-Bradley 1336 FORCE User Manual

Chapter 5
Programming Parameters
5–71
Data In B2
[Data In B2]
Data In C1
[Data In C1]
Data In C2
[Data In C2]
Data In D1
[Data In D2]
This parameter displays the SCANport to
drive image which is received from some
device on SCANport.
Parameter Number 313
Parameter Type Source
Display Units +/–x
Drive Units None
Factory Default 0
Minimum Value –32767
Maximum Value +32767
Parameter Number 314
Parameter Type Source
Display Units +/–x
Drive Units None
Factory Default 0
Minimum Value –32767
Maximum Value +32767
This parameter displays the SCANport to
drive image which is received from some
device on SCANport.
Parameter Number 315
Parameter Type Source
Display Units +/–x
Drive Units None
Factory Default 0
Minimum Value –32767
Maximum Value +32767
This parameter displays the SCANport to
drive image which is received from some
device on SCANport.
This parameter displays the SCANport to
drive image which is received from some
device on SCANport.
Parameter Number 316
Parameter Type Source
Display Units +/–x
Drive Units None
Factory Default 0
Minimum Value –32767
Maximum Value +32767
Parameter Number 317
Parameter Type Source
Display Units +/–x
Drive Units None
Factory Default 0
Minimum Value –32767
Maximum Value +32767
Data In D2
[Data In D2]
Data Out A1
[Data Out A1]
Data Out A2
[Data Out A2]
This parameter displays the drive to
SCANport image which is sent to some
device on SCANport
This parameter displays the SCANport to
drive image which is received from some
device on SCANport.
This parameter displays the drive to
SCANport image which is sent to some
device on SCANport
Parameter Number 321
Parameter Type Source
Display Units +/–x
Drive Units None
Factory Default 0
Minimum Value –32767
Maximum Value +32767
Parameter Number 320
Parameter Type Sink
Display Units +/–x
Drive Units None
Factory Default 0
Minimum Value –32767
Maximum Value +32767
Data Out B1
[Data Out B1]
This parameter displays the drive to
SCANport image which is sent to some
device on SCANport
Parameter Number 322
Parameter Type Sink
Display Units +/–x
Drive Units None
Factory Default 0
Minimum Value –32767
Maximum Value +32767
