Allen-Bradley 1336 FORCE User Manual

Chapter 5
Programming Parameters
5–84
Pulse Value
[Pulse Value]
Parameter Number 399
Parameter Type Source
Display Units x.x RPM
Drive Units 4096 = Pulse Scale
Factory Default 0.0
Minimum Value –8 x Pulse Scale
Maximum Value +8 x Pulse Scale
This parameter displays the pulse input
value.
Pulse Offset
[Pulse Offset]
Parameter Number 398
Parameter Type Sink
Display Units x.x RPM
Drive Units None
Factory Default 0.0
Minimum Value – Pulse Scale
Maximum Value + Pulse Scale
This parameter determines the minimum
speed the pulse input will go to.
This parameter determines the pulse input
speed that is equal to 4096 drive units.
Pulse Scale
[Pulse Scale]
Parameter Number 397
Parameter Type Sink
Display Units x RPM
Drive Units 4096
Factory Default 1750
Minimum Value –6000
Maximum Value +6000
SP Comm Retries
[SP Comm Retries]
Parameter Number 404
Parameter Type Source
Display Units x.
Drive Units
Factory Default 0.0
Minimum Value 0
Maximum Value 65535
This parameter monitors the amount of
SCANport communications errors
that have occurred since power up.
Pulse PPR
[Pulse PPR]
Parameter Number 395
Parameter Type Sink
Display Units x PPR
Drive Units None
Factory Default 1024
Minimum Value 500
Maximum Value 20000
This parameter determines the pulse input
pulses per revolution.
Pulse Single or Double Edge
[Pulse Edge]
Parameter Number 396
Parameter Type Sink
Display Units None
Drive Units None
Factory Default 1
Minimum Value 1
Maximum Value 2
Enums:
1 = 1 Edge
2 = 2 Edges
This parameter determines if rising (single)
or rising and falling (double) edges are
counted for the pulse input.
