Chapter 2
Installation/Wiring
2–3
Figure 2.3.
IP 20 (NEMA Type 1) Dimensions – Frame D
D
A
Y
CC
E
B
Z
BB
AA
7.0 (0.28)
7.0 (0.28)
12.7 (0.50)
12.7 (0.50)
Mounting Holes (4)
Knockouts
All Dimensions in Millimeters and (Inches)
All Weights in Kilograms and (Pounds)
Knockouts
3–Dual Size, 3–Fixed
62.7/76.2, 34.9/50.0, 34.9
(2.47/3.00, 1.38/1.97, 1.38)
Shipping
Weight
108.9 kg
(240 lbs.)
CC
71.9
(2.83)
Frame
1
Reference
D
A
381.5
(15.02)
B
1240.0
(48.82)
C Max.
270.8
(10.66)
D
325.9
(12.83)
E
1216.2
(47.88)
Y
27.94
(1.10)
Z
11.94
(0.47)
AA
131.1
(5.16)
BB
688.6
(27.11)
C Max.
