Chapter 2
Installation/Wiring
2–7
Figure 2.7.
IP 20 (NEMA Type 1) Dimensions – Frame H
Removable Lifting Angle
2324.1
(91.50)
All Dimensions in Millimeters and (Inches)
635.0
(25)
508.0
(20)
762.0
(30)
Conduit Access
Area
Conduit Access
Area
Top View
Bottom View
Top Mounted Fan
635.0
(25.00)
1270.0
(50)
1270.0
(50)
635.0
(25)
Manufacturer-dependent,
may be shorter.
