Allen-Bradley 1336 FORCE User Manual

Chapter 2
Installation/Wiring
2–6
Figure 2.6.
IP 20 (NEMA Type 1) Dimensions – Frame G
2324.1
(91.50)
Removable Lifting Angle
762.0
(30.00)
63.5 (2.50)
635.0
(25.00)
All Dimensions in Millimeters and (Inches)
All Weights in Kilograms and (Pounds)
29.0
(1.14)
15.9 (0.63) Dia.
– 2 Mtg. Holes –
431.8
(17.00)
381.0
(15.00)
298.5
(11.75)
42.9
(1.69)
254.0
(10.00)
547.6
(21.56)
Conduit Access Area
660.4
(26.00)
50.8
(2.00)
431.8
(17.00)
(Top)
Conduit
Access Area
(Bottom)
Shipping Weight
453.6 kg
(1000 lb)
