Allen-Bradley 1336 FORCE User Manual

Chapter 2
Installation/Wiring
2–5
Figure 2.5.
IP 20 (NEMA Type 1) Dimensions – Frame F
2286.0
(90.00)
762.0
(30.00)
252.7
(9.95)
635.0
(25.00)
37.9
(1.49
)
274.8
(10.82)
193.0
(7.60)
1219.2
(48.00)
All Dimensions in Millimeters and (Inches)
Conduit
Access Area
Bottom View
31.5
(1.24)
698.5
(27.50)
298.5
(11.75)
50.8
(2.00)
Shipping Weight
415.0 kg
(915 lbs)
