102 Rockwell Automation Publication 1444-UM001D-EN-P - June 2018
Chapter 3 Configure the 1444 Dynamic Measurement Module
Ch0, Ch1, Ch2,
Ch3
0: Off
1: Dynamic
2: gSE
3: Static
Channel Type is a high-level selection that is used by the AOP (not the module) to
filter / manage further user selections in Module Definition and in Configuration.
The Channel Types that are enabled are based on the Module Personality selected.
The selections are as follows.
Table 15 - Module Functionality
Parameter Values Comment
Personality Ch0 Ch1 Ch2 Ch3
Real Time, 4 Ch –
Dynamic (4 kHz)
or Static
Off,
Dynamic,
Static
Off,
Dynamic,
Static
Off,
Dynamic,
Static
Off,
Dynamic,
Static
Real Time, 2 Ch –
Dynamic
(20 kHz), 2 Ch
Static
Off, Dynamic Off,
Ch0 Setting
Off,
Static
Off,
Static
Real Time, 4 Ch –
Dynamic (4 kHz)
– Dual Path
Off,
Dynamic,
Static
Off,
Ch0 Setting
Off,
Dynamic,
Static
Off,
Ch2 Setting
Real Time, 2 Ch –
Dynamic (40 kHz)
Off,
Dynamic,
gSE
Off,
Ch0 Setting
Off Off
Multiplexed, 4 Ch
– Dynamic
(40 kHz) or Static
– Paired
Off,
Dynamic,
gSE,
Static
Off,
Ch0 Setting
Off,
Dynamic,
gSE,
Static
Off,
Ch2 Setting
Multiplexed, 4 Ch
– Dynamic
(40 kHz) or Static
– Individual
Off,
Dynamic,
gSE,
Static
Off,
Dynamic,
gSE,
Static
Off,
Dynamic,
gSE,
Static
Off,
Dynamic,
gSE,
Static
