Rockwell Automation Publication 1444-UM001D-EN-P - June 2018 325
CIP Objects Appendix A
*See Measurement ID Definition on page 325 to interpret the contents of the
StaticParams and DiscreteParams attributes.
Measurement ID Definition
Throughout the configuration, there are several parameters that are used to
either indicate a specific measurement, or that indicate some set of
measurements.
Measurement IDs (INT values) and Parameter Arrays (DINT[4]) refer to the
parameters shown inTable 84
and Table 85. These parameters define one (ID)
or multiple (Parameter Array) data values that are used in the control.
Examples
• Measurement ID: On the Analog Output page, four Measurement IDs
are defined, one per channel, which specify the parameter to output on
the channel. In these cases, the INT refers to the Index in the table to
point to the measurement that is output.
• Parameter Array: On the Trend Page, four StaticParams attributes are
defined, each is a DINT value. In this case, the specific bits that are set in
the 4 DINTs define which measurements are included in the discrete
data for the Trend.
The configuration includes the following Measurement ID parameters.
Table 84 - Measurement ID Parameters
The configuration includes the following Parameter Array parameters.
Table 85 - Parameter Array Parameters
Page Parameter Tag Member Object Attribute
Analog Output Measurement Ch0…3AnalogOut.MeasurementID Dynamix Current Output Module Object Current Output Measurement Identifier
Measurement Alarm Measurement MeasAlarm00…23.ID Dynamix Measurement Alarm Object Alarm Measurement Identifier
Page Parameter Tag Member Object Attribute
Trend Data-Set Definition Trend.StaticParams0…3 Dynamix Data Manager Object DWORD 0…3
Transient Data-Set Definition Trend.DiscreteParams0…3 Dynamix Data Manager Object DWORD 0…3
