326 Rockwell Automation Publication 1444-UM001D-EN-P - June 2018
Appendix A CIP Objects
Table 86 - Discrete Parameter Bit Definition
Index DINT Bit Descriptor Tag
0 0 Overall (0) Channel 0 Ch0Overall0
1 1 Overall (0) Channel 1 Ch1Overall0
2 2 Overall (0) Channel 2 Ch2Overall0
3 3 Overall (0) Channel 3 Ch3Overall0
4 4 Overall (1) Channel 0 Ch0Overall1
5 5 Overall (1) Channel 1 Ch1Overall1
6 6 Overall (1) Channel 2 Ch2Overall1
7 7 Overall (1) Channel 3 Ch3Overall1
8 8 DC(V) Channel 0 Ch0DCV
9 9 DC(V) Channel 1 Ch1DCV
10 10 DC(V) Channel 2 Ch2DCV
11 11 DC(V) Channel 3 Ch3DCV
12 0 12 Order (0) Mag Channel 0 Ch0Order0Mag
13 13 Order (0) Mag Channel 1 Ch1Order0Mag
14 14 Order (0) Mag Channel 2 Ch2Order0Mag
15 15 Order (0) Mag Channel 3 Ch3Order0Mag
16 16 Order (0) Phase Channel 0 Ch0Order0Phase
17 17 Order (0) Phase Channel 1 Ch1Order0Phase
18 18 Order (0) Phase Channel 2 Ch2Order0Phase
19 19 Order (0) Phase Channel 3 Ch3Order0Phase
20 20 Order (1) Mag Channel 0 Ch0Order1Mag
21 21 Order (1) Mag Channel 1 Ch1Order1Mag
22 22 Order (1) Mag Channel 2 Ch2Order1Mag
23 23 Order (1) Mag Channel 3 Ch3Order1Mag
24 24 Order (1) Phase Channel 0 Ch0Order1Phase
25 25 Order (1) Phase Channel 1 Ch1Order1Phase
26 26 Order (1) Phase Channel 2 Ch2Order1Phase
27 27 Order (1) Phase Channel 3 Ch3Order1Phase
28 28 Order (2) Mag Channel 0 Ch0Order2Mag
29 29 Order (2) Mag Channel 1 Ch1Order2Mag
30 30 Order (2) Mag Channel 2 Ch2Order2Mag
31 31 Order (2) Mag Channel 3 Ch3Order2Mag
32 0 Order (2) Phase Channel 0 Ch0Order2Phase
33 1 Order (2) Phase Channel 1 Ch1Order2Phase
34 2 Order (2) Phase Channel 2 Ch2Order2Phase
35 3 Order (2) Phase Channel 3 Ch3Order2Phase
36 4 Order (3) Mag Channel 0 Ch0Order3Mag
37 5 Order (3) Mag Channel 1 Ch1Order3Mag
