CIP Objects Appendix A
Configuration Groups 5…16
The Measurement Alarm Object has 24 instances, spread across 12 groups
(two instances per configuration group).
In the following table, for a particular group, N = 1 + (2*(Group- 5))
Examples
• Group 5: N = 1 (source instances 1 and 2)
–to
• Group 16: N = 23 (source instances 23 and 24)
Table 98 - Configuration Groups 5...16
Source Object Source Instance Source Attribute ID Name Data Type
0x396 N 16 Alarm Enable SINT
- - - Pad SINT
0x396 N 17 Alarm Measurement Identifier INT
19 Alarm Form SINT
20 Alarm Type SINT
21 Alarm Processing Mode SINT
- - - Pad SINT
0x396 N 24 Low Alert Threshold REAL
25 High Alert Threshold REAL
26 Low Danger Threshold REAL
27 High Danger Threshold REAL
32 Hysteresis SINT
- - - Pad SINT
- - - Pad INT
0x396 N 33 Delay/Sustain Time (Alert) DINT
34 Delay/Sustain Time (Danger) DINT
35 Alarm Multiplier REAL
40 Adaptive Monitoring Source INT
- - - Pad INT
