358 Rockwell Automation Publication 1444-UM001D-EN-P - June 2018
Appendix A CIP Objects
0x396 N 41 Range 1 - upper control value REAL
42 Range 1 - Alarm Multiplier REAL
43 Range 2 - upper control value REAL
44 Range 2 - Alarm Multiplier REAL
45 Range 3 - upper control value REAL
46 Range 3 - Alarm Multiplier REAL
47 Range 4 - upper control value REAL
48 Range 4 - Alarm Multiplier REAL
49 Range 5 - upper control value REAL
50 Range 5 - Alarm Multiplier REAL
64 Profile mode - Reference for Low Alert Threshold SINT
65 Profile mode - Reference for High Alert Threshold SINT
66 Profile mode - Reference for Low Danger Threshold SINT
67 Profile mode - Reference for High Danger Threshold SINT
0x396 N+1 16 Alarm Enable SINT
- - - Pad SINT
0x396 N+1 17 Alarm Measurement Identifier INT
19 Alarm Form SINT
20 Alarm Type SINT
21 Alarm Processing Mode SINT
- - - Pad SINT
0x396 N+1 24 Low Alert Threshold REAL
25 High Alert Threshold REAL
26 Low Danger Threshold REAL
27 High Danger Threshold REAL
32 Hysteresis SINT
- - - Pad SINT
- - - Pad INT
0x396 N+1 33 Delay/Sustain Time (Alert) DINT
34 Delay/Sustain Time (Danger) DINT
35 Alarm Multiplier REAL
40 Adaptive Monitoring Source INT
- - - Pad INT
0x396 N+1 41 Range 1 - upper control value REAL
42 Range 1 - Alarm Multiplier REAL
43 Range 2 - upper control value REAL
44 Range 2 - Alarm Multiplier REAL
45 Range 3 - upper control value REAL
Table 98 - Configuration Groups 5...16 (continued)
Source Object Source Instance Source Attribute ID Name Data Type
