476 Rockwell Automation Publication 1444-UM001D-EN-P - June 2018
Appendix A CIP Objects
Attribute Semantics
Enabled Instances
The enable/disable state of the 32 instances, is available bit-wise from a
DWORD, where at a bit level.
Disabled instances return error 0x08 (Service Not supported) when disabled
instances are addressed with common services.
When 1, attribute 23 sets tacho source.
17 Get V Data Source SINT The Module Control Object, attributes
73, 80, 87, and 94, sets the data source
for FFT bands.
Fixed at 0
Demanded Band Frequency Limits
Group of four configuration attributes.
18 Get V Source of Band Frequency Limits SINT Tacho related or fixed band limits in
Hz.
Band type
19 Get V Start Frequency REAL Definition of demanded band start
frequency in Hz or orders (refer 18).
Start < Stop
Start > 0
Range: 0.1…39000
20 Get V Stop Frequency REAL Definition of demanded band stop
frequency in Hz or orders (refer 18).
Stop > Start
Stop < Fmax
Range: 0.2…40000
23 Get V Tacho Source for Band Limits SINT Tacho source for band limits. Tacho source
Transfer of Data to Controller
A configuration attribute.
24 Get V FFT Band magnitude - Type SINT Which measurement data is
transferred for this band (RMS, max,
or Frequency).
0, 1, 2
Band RMS (default)
max line/bin value
Frequency of max line (Hz / order)
Table 214 - Instance Attributes (continued)
Table 215 - Enabled Instances
Value Description
0 Disabled
1 Enabled
Table 216 - Band Type
Value Description
0 Fixed bands in Hz
1 Order related bands
