Rockwell Automation Publication 1444-UM001D-EN-P - June 2018 351
CIP Objects Appendix A
Configuration Group 3
Group 3 contains configuration attributes from these objects:
• Relay Module Object (0x39C)
• Dual Measurement Object (0x392)
• AC Measurement Object (0x390)
Table 96 - Configuration Group 3
Source Object Source Instance Source Attribute ID Name Data Type
0x39C 1 17 Relay 0 Source SINT
18
Relay 1 Source SINT
19 Relay 2 Source SINT
20 Relay 3 Source SINT
0x39C 1 36 Relay 0 User Relay Control BYTE
37 Relay 1 User Relay Control BYTE
38 Relay 2 User Relay Control BYTE
39 Relay 3 User Relay Control BYTE
0x39C 2 17 Relay 0 Source SINT
18 Relay 1 Source SINT
19
Relay 2 Source SINT
20 Relay 3 Source SINT
0x39C 2 36 Relay 0 User Relay Control BYTE
37 Relay 1 User Relay Control BYTE
38 Relay 2 User Relay Control BYTE
39 Relay 3 User Relay Control BYTE
0x39C 3 17 Relay 0 Source SINT
18
Relay 1 Source SINT
19
Relay 2 Source SINT
20
Relay 3 Source SINT
0x39C 3 36 Relay 0 User Relay Control BYTE
37 Relay 1 User Relay Control BYTE
38 Relay 2 User Relay Control BYTE
39 Relay 3 User Relay Control BYTE
0x392 1 16 Sensor 0 Ramp Angle REAL
17 Sensor 1 Ramp Angle REAL
18 Overall Axial Offset 0/1 REAL
19 Overall Radial Offset 0/1 REAL
0x392 2 16 Sensor 2 Ramp Angle REAL
17 Sensor 3 Ramp Angle REAL
18 Overall Axial Offset 2/3 REAL
19 Overall Radial Offset 2/3 REAL
To Next Page
