Ethernet Port Status Indicators
Each Ethernet port RJ45 jack is fitted with two status indicators.
OS Operating
Status
Powered off OK / Normal Redundant
power fail
If DSP Status
Indicator is
flashing
green:
Configuring
If DSP Status
Indicator is
solid green or
off: Storing
to memory
— Inhibit — Firmware
update in
process
—
DSP DSP Run Powered off DSP paused
or not
running
DSP running — Setpoint
Multiplier
active
— DSP is in boot
loader mode
——
OK DSP Status Powered off
or channels
are disabled
during the
configuration
transfer
process
OK ———Calibration,
DSP, or
configuration
error
—Firmware
update in
process
—
CH0 Channel 0
status
Channel
disabled
Channel OK/
TX OK
———Channel TX
Fault
———
CH1 Channel 1
status
Channel
disabled
Channel OK/
TX OK
———Channel TX
Fault
———
CH2 Channel 2
status
Channel
disabled
Channel OK/
TX OK
———Channel TX
Fault
———
CH3 Channel 3
status
Channel
disabled
Channel OK/
TX OK
———Channel TX
Fault
———
RLY Relay status Relay not in
use
Relay not in
alarm
—Relay
inhibited
—Relay in
alarm
(actuated)
———
