Rockwell Automation Publication 1444-UM001D-EN-P - June 2018 109
Configure the 1444 Dynamic Measurement Module Chapter 3
Internet Protocol Page
The Internet Protocol page parameters provide controls for connecting the
module to a network. See ENET-UM001
for more information.
Figure 47 - The Internet Protocol Page
IMPORTANT The module must be ONLINE for the Internet Protocol page to update.
Table 18 - Internet Protocol
Parameter Values Comments
Internet Protocol Settings Manually configure IP settings
Use BOOTP to obtain IP settings
automatically
Use DHCP to obtain IP settings
automatically
IP settings set by switches on the module
Physical Module IP address — Type an IP address for the system.
Domain Name —
Host Name —
Subnet Mask —
Gateway Address —
Primary DNS Server Address —
Secondary DNS Server
Address
—
