Chapter 2 Install the Dynamix 1444 Series Monitoring System
Wiring Requirements
All modules (whether main or Expansion) have four removable connectors
where the field wiring is made. They come in a choice of spring cage or screw
connection. Both types benefit from the following:
• Screwdriver axis parallel to conductor axis
• Positive connector retention (captive screws)
• Test connections for 1.2 mm (0.047 in.) diameter test pins or 1 mm
(0.039 in.) test plugs
The DYN module connectors are 16 way and the expansion module
connectors are 6 way. Each is keyed appropriate to location and module type.
Manufacturer technical data for these connectors is as follows.
WARNING: All wiring must comply with applicable electrical installation
requirements (for example, N.E.C. article 501-4(b)).
Attribute Value
Tightening torque, min- max (screw type only) 0.22…0.25 N•m (0.16…0.18 ft·lbf)
Normal cross-section 1.5 mm
2
(0.002 in)
Stripping length 9 mm (0.35 in)
Conductor cross-section solid or stranded min- max 0.14…1.5 mm
2
(0.0002…0.002 in)
Conductor cross-section stranded with ferrule without
plastic sleeve min- max
0.25…1.5 mm
2
(0.0003…0.002 in)
Conductor cross-section stranded with ferrule with plastic
sleeve min- max
0.25…0.5 mm
2
(0.0003…0.0007 in)
Conductor cross-section AWG/kcmil min- max - screw
clamp type
28…16 mm
2
Conductor cross-section AWG/kcmil min- max - spring
clamp type
26…16 mm
2
AWG according to ULL/CUL min- max -screw clamp type 30…16 mm
2
AWG according to ULL/CUL min- max -spring clamp type 28…16 mm
2
