Rockwell Automation Publication 1444-UM001D-EN-P - June 2018 91
Chapter 3
Configure the 1444 Dynamic
Measurement Module
This chapter details how to define and configure the 1444 dynamic
measurement module and set associated parameters.
Topic Page
General Page 92
Module Definition 92
Internet Protocol Page 109
Port Configuration Page 110
Time Sync Page 110
Hardware Configuration Page 111
Time Slot Multiplier Page 118
Speed Page 121
IMPORTANT Many parameters within the AOP are named differently than the objects
within the module that they refer to. Consequently, some parameter names
that are listed in the CIP™ Objects Library (CIP Objects
on page 317), do not
match the parameters that are presented on the AOP.
See the cross-reference at the beginning of the CIP Objects Library to
determine the specific names of parameters as presented on the AOP, stored
in the configuration assembly, and held in the various objects in the module.
