Rockwell Automation Publication 1444-UM001D-EN-P - June 2018 317
Appendix A
CIP Objects
This appendix defines the specific CIP™ Objects supported by the Dynamix™
measurement module.
Topic Page
Parameter – Tag – Object Attribute Cross-reference 318
Reading TWF and FFT Data 331
Dynamix Specific Objects
Dynamix Configuration Manager Object 338
Dynamix Data Manager Object 384
Dynamix Transient Data Manager Object 397
Dynamix Event Log Object 406
Dynamix Transducer Object 415
Dynamix Channel Setup Object 418
Dynamix AC Measurement Object 422
Dynamix DC Measurement Object 426
Dynamix Dual Measurement Object 430
Dynamix Tracking Filter Object 434
Dynamix TSC Module Object 439
Dynamix Tacho and Speed Measurement Object 444
Dynamix Measurement Alarm Object 448
Dynamix Voted Alarm Object 455
Dynamix Normal CM Data Object 464
Dynamix FFT Band Object 475
Dynamix Advanced CM Data Object 477
Dynamix Relay Module Object 495
Dynamix Current Output Module Object 503
Dynamix Module Control Object 506
Generic Objects
Identity Object 515
Message Router Object 516
Assembly Object 517
File Object 529
Time Sync Object 531
Device Level Ring Object 534
Quality of Service Object 535
TCP/IP Interface Object 536
