Rockwell Automation Publication 1444-UM001D-EN-P - June 2018 231
Chapter 9
Trend and Transient Capture
This chapter explains trends and transient capture.
Trend Page
Page Overview
The dynamic measurement module includes a trend buffer capability that
captures a set of internal data records. The internal data records are sampled at
a defined periodicity and they span a defined amount of time. The module also
supports an Alarm Buffer, a copy of the trend buffer, with additional high-
resolution data at the trigger point, which is saved and held upon a user-
defined trigger.
Topic Page
Trend Page 231
Transient Capture Page 236
