Rockwell Automation Publication 1444-UM001D-EN-P - June 2018 193
Chapter 5
Configure the Tachometer Expansion Module
Tachometer Expansion
Module
The 1444-TSCX02-02RB Tachometer Signal Conditioner Expansion Module
is a two-channel monitor that converts input signals from common speed-
sensing transducers into a once-per-revolution TTL class signal. The expansion
module is suitable for use by up to six connected 1444-DYN04-01RA dynamic
measurement modules.
The tachometer signal conditioner commonly serves speed signals to main
modules other than its host. So, unlike other expansion modules, and except
for configuration services, the 1444-TSCX02-02RB module operates
independently of its host module. Therefore, once configured, the tachometer
expansion module continuously serves TTL speed signals, regardless of the
state or availability of its host module or local bus.
Topic Page
Tachometer Expansion Module 193
Tachometer Page 194
