Rockwell Automation Publication 1444-UM001D-EN-P - June 2018 415
CIP Objects Appendix A
Dynamix Transducer Object
The transducer object (class code 0x38E)defines the properties of the sensor
that is connected to one of the four available physical inputs.
Attributes describe physical measurement parameters and transducer OK
monitoring setup, as also some sensor-mounting geometry settings.
This object reports transducer DC Volts (bias) measurement and transducer
status.
Table 144 - Object Instances
Instance ID Description
0 Transducer Class Instance
Table 145 - Class Attributes
Attribute
ID
Access
Rule
NV Name Data
Type
Description of
Attribute
Semantics of Values
1 Get NV Revision UINT Current object revision. Current revision.
8 Get V TX Overall Status BYTE Coded information to
represent transducer
Enabled and OK status
Bits 0…3 represent
transducer
enabled status (1 =
enabled).
Bits 4…7 represent
transducer OK status (1
= OK).
Table 146 - Instance Attributes
Attribute ID Access Rule NV Name Data Type Description of Attribute Semantics of Values
1 Get V DC Bias REAL The DC level at the input in fixed
units of DC Volts.
Data
2 Get V TX Detailed Status BYTE Detailed bit-coded Transducer
Status (Data).
See TX OK Configuration Decoding
Transducer Descriptions Group of four attributes that are used for reference purposes only.
16 Get V Transducer Name SINT[32] Descriptive name. 32 characters
17 Get V Transducer Orientation INT Definition of sensor orientation
angle in degrees. Orientation
angle is usually a radial angular
orientation.
0…359 degree input range in
increments of 1 °
18 Get V Transducer Location SINT Transducer location definition. 0: Unknown
1: Radial
2: Axial
19 Get V Transducer Output Sense SINT Sensor output sense - information
only. The DC measurement object
has normal/counter control.
Fixed at zero
Transducer Output Definition Group of five configuration attributes.
24 Get V Transducer AC Units ENGUNITS Transducer measurement units
that are used for AC measurement
base.
Supported engineering units
25 Get V Transducer AC Sensitivity REAL TX AC Sensitivity in mV/TX AC
units.
Range: 1…20000
26 Get V Transducer DC Units ENGUNITS Transducer measurement units
that are used for DC measurement
base.
Supported engineering units
