Rockwell Automation Publication 1444-UM001D-EN-P - June 2018 441
CIP Objects Appendix A
Attribute Semantics
TSC Module Status
The Auxiliary TSC module reports its status as part of the normal exchanges
with the main module.
The bit assignments are as follows.
Bits 0…7 are common to all types of auxiliary module, bits 8 to 15 are specific
to type.
The auxiliary module controls Bits 1…15, the main module sets bit 0.
If bit 0 is set, the remaining bits do not reflect the current auxiliary module
status.
If communication with an expansion module is lost, then the main module sets
a status bit to indicate an expansion bus fault. If communication are restored,
then normally the fault indication clears. However, if a configuration activity
has failed, then the fault indication remains set until a successful
reconfiguration is completed. Normally this reconfiguration is achieved by
downloading the configuration from the controller to the host main module.
Bit Description
0 Auxiliary module is not responding
1 Auxiliary module that is configured
2 MSP code (CRC) fault
3 MSP high temperature
4 Link fail
5 Halt active
6 MSP RAM fault
7 MSP RAM access error
Bit Description
8 Reserved for reverse rotation detected
9 Reserved for zero speed detected
10 Speed 0 is estimated
11 Speed 1 is estimated
12 +25V5 supply fail
13 -25V5 supply fail
14 Tacho 0 sensor fail
15 Tacho 1 sensor fail
