Page #442 background imageLoading...
Page #442 background image
442 Rockwell Automation Publication 1444-UM001D-EN-P - June 2018
Appendix A CIP Objects
Tacho Input Types
Following sensor types are supported for connection to Tacho Signal
Conditioning expansion module.
TX Power Setup
Following transducer power-supply options apply per transducer output.
Value Description
0 OFF
1 TTL Signal Input
2 NPN Proximity Switch
3 PNP Proximity Switch
4 Eddy Current Probe System
5 Self-generating magnetic Probe
Value Description
0 OFF
1 +CV (+24V / 25 mA voltage regulated output)
2 -CV (-24V / 25 mA voltage regulated output)
