350 Rockwell Automation Publication 1444-UM001D-EN-P - June 2018
Appendix A CIP Objects
- - - Pad INT
0x394 1 33 Trigger Threshold INT
34 Trigger Slope/Edge SINT
40 Sensor OK Definition BYTE
41 Sensor OK High Threshold INT
42 Sensor OK Low Threshold INT
43 High RPM Threshold REAL
44 Low RPM Threshold REAL
48 Tacho Bus Output SINT
49 TSCX Terminal/BNC Output SINT
- - - Pad INT
0x394 2 16 Input Sensor Type SINT
24 Sensor Power Supply SINT
25 Sensor Target, pulses per revolution INT
32 Trigger Mode SINT
- - - Pad SINT
- - - Pad INT
0x394 2 33 Trigger Threshold INT
34 Trigger Slope/Edge SINT
40 Sensor OK Definition BYTE
41 Sensor OK High Threshold INT
42 Sensor OK Low Threshold INT
43 High RPM Threshold REAL
44 Low RPM Threshold REAL
48 Tacho Bus Output SINT
49 TSCX Terminal/BNC Output SINT
- - - Pad INT
Table 95 - Configuration Group 2 (continued)
Source Object Source Instance Source Attribute ID Name Data Type
