Rockwell Automation Publication 1444-UM001D-EN-P - June 2018 349
CIP Objects Appendix A
0x39E 0 87 Channel 2 DSP FFT Signal Source SINT
88 Channel 2 DSP FFT Measurement Units ENGUNITS
89 Channel 2 DSP FFT Line Resolution SINT
90 Channel 2 DSP FFT Window Function SINT
91 Channel 2 DSP FFT Number of averages SINT
92 Channel 2 DSP FFT Line value detection/scaling SINT
93 Channel 3 DP FFT Enable SINT
94 Channel 3 DSP FFT Signal Source SINT
95 Channel 3 DSP FFT Measurement Units ENGUNITS
96 Channel 3 DSP FFT Line Resolution SINT
97 Channel 3 DSP FFT Window Function SINT
98 Channel 3 DSP FFT Number of averages SINT
99 Channel 3 DSP FFT Line value detection/scaling SINT
0x395 1 16 Tacho source SINT
17 Tacho OK Source SINT
- - - Pad INT
0x395 1 19 Speed Multiplier REAL
21 Tacho Trigger Slope/Edge SINT
- - - Pad SINT
- - - Pad INT
0x395 1 24 ROC Delta Time REAL
25 ROC TC REAL
0x395 2 16 Tacho source SINT
17 Tacho OK Source SINT
- - - Pad INT
0x395 2 19 Speed Multiplier REAL
21 Tacho Trigger Slope/Edge SINT
- - - Pad SINT
0x395 - - Pad INT
0x395 2 24 ROC Delta Time REAL
25 ROC TC REAL
0x394 0 18 Mode Control BYTE
- - - Pad SINT
- - - Pad INT
0x394 1 16 Input Sensor Type SINT
24 Sensor Power Supply SINT
25 Sensor Target, pulses per revolution INT
32 Trigger Mode SINT
- - - Pad SINT
Table 95 - Configuration Group 2 (continued)
Source Object Source Instance Source Attribute ID Name Data Type
