348 Rockwell Automation Publication 1444-UM001D-EN-P - June 2018
Appendix A CIP Objects
0x38F 3 22 Synchronous samples per revolution INT
23 Alternate Path Decimation INT
24 Alternate LP Filter -3 dB Point REAL
0x38F 4 16 LP Filter -3 dB Point REAL
17 HP Filter -3 dB Point REAL
18 Decimation INT
19 SRD SINT
20 Alternate Path enable SINT
21 Synchronous Tacho Source SINT
- - - Pad SINT
- - - Pad INT
0x38F 4 22 Synchronous samples per revolution INT
23 Alternate Path Decimation INT
24 Alternate LP Filter -3 dB Point REAL
0x39E 0 16 Configured Auxiliary Modules BYTE
24 Tacho Mode SINT
32 Opto Output 0 Allocation SINT
33 Opto Output 1 Allocation SINT
40 User Local Relay Control BYTE
42 Relay Source SINT
64 Redundant Power Supply SINT
- - - Pad SINT
0x39E 0 72 Channel 0 DSP FFT Enable SINT
73 Channel 0 DSP FFT Signal Source SINT
74 Channel 0 DSP FFT Measurement Units ENGUNITS
75 Channel 0 DSP FFT Line Resolution SINT
76 Channel 0 DSP FFT Window Function SINT
77 Channel 0 DSP FFT Number of averages SINT
78 Channel 0 DSP FFT Line value detection/scaling SINT
79 Channel 1 DP FFT Enable SINT
80 Channel 1 DSP FFT Signal Source SINT
81 Channel 1 DSP FFT Measurement Units ENGUNITS
82 Channel 1 DSP FFT Line Resolution SINT
83 Channel 1 DSP FFT Window Function SINT
84 Channel 1 DSP FFT Number of averages SINT
85 Channel 1 DSP FFT Line value detection/scaling SINT
86 Channel 2 DP FFT Enable SINT
Table 95 - Configuration Group 2 (continued)
Source Object Source Instance Source Attribute ID Name Data Type
