CIP Objects Appendix A
Configuration Group 2
Group 2 contains configuration attributes from these objects:
• Channel setup Object (0x38F)
• Module Control Object (0x39E)
• Tacho and Speed Measurement Object (0x395)
• TSC Module Object (0x394)
Table 95 - Configuration Group 2
Source Object Source Instance Source Attribute ID Name Data Type
0x38F 1 16 LP Filter -3 dB Point REAL
17 HP Filter -3 dB Point REAL
18 Decimation INT
19 SRD SINT
20 Alternate Path enable SINT
21 Synchronous Tacho Source SINT
- - - Pad SINT
- - - Pad INT
0x38F 1 22 Synchronous samples per revolution INT
23 Alternate Path Decimation INT
24 Alternate LP Filter -3 dB Point REAL
0x38F 2 16 LP Filter -3 dB Point REAL
17 HP Filter -3 dB Point REAL
18 Decimation INT
19 SRD SINT
20 Alternate Path enable SINT
21 Synchronous Tacho Source SINT
- - Pad SINT
- - Pad INT
0x38F 2 22 Synchronous samples per revolution INT
23 Alternate Path Decimation INT
24 Alternate LP Filter -3 dB Point REAL
0x38F 3 16 LP Filter -3 dB Point REAL
17 HP Filter -3 dB Point REAL
18 Decimation INT
19 SRD SINT
20 Alternate Path enable SINT
21 Synchronous Tacho Source SINT
- - - Pad SINT
- - - Pad INT
