352 Rockwell Automation Publication 1444-UM001D-EN-P - June 2018
Appendix A CIP Objects
0x390 1 17 AC Overall Measurement Units ENGUNITS
---Pad INT
0x390 1 18 AC Overall Measurement RMS TC REAL
19 AC Overall Measurement Peak TC REAL
20 AC Overall magnitude - Detection SINT
32 Configure Peak per revolution SINT
---Pad INT
0x390 1 33 Minimum RPM for Peak per revolution REAL
0x390 2 16 AC Overall Measurement Source SINT
---Pad SINT
0x390 2 17 AC Overall Measurement Units ENGUNITS
18 AC Overall Measurement RMS TC REAL
19 AC Overall Measurement Peak TC REAL
20 AC Overall magnitude - Detection SINT
---Pad SINT
---Pad INT
0x390 3 17 AC Overall Measurement Units ENGUNITS
---Pad INT
0x390 3 18 AC Overall Measurement RMS TC REAL
19 AC Overall Measurement Peak TC REAL
20 AC Overall magnitude - Detection SINT
32 Configure Peak per revolution SINT
---Pad INT
0x390 3 33 Minimum RPM for Peak per revolution REAL
0x390 4 16 AC Overall Measurement Source SINT
---Pad SINT
0x390 4 17 AC Overall Measurement Units ENGUNITS
18 AC Overall Measurement RMS TC REAL
19 AC Overall Measurement Peak TC REAL
20 AC Overall magnitude - Detection SINT
---Pad SINT
---Pad INT
0x390 5 17 AC Overall Measurement Units ENGUNITS
---Pad INT
0x390 5 18 AC Overall Measurement RMS TC REAL
19 AC Overall Measurement Peak TC REAL
20 AC Overall magnitude - Detection SINT
32 Configure Peak per revolution SINT
---Pad INT
Table 96 - Configuration Group 3 (continued)
Source Object Source Instance Source Attribute ID Name Data Type
