Rockwell Automation Publication 1444-UM001D-EN-P - June 2018 327
CIP Objects Appendix A
38 6 Order (3) Mag Channel 2 Ch2Order3Mag
39 7 Order (3) Mag Channel 3 Ch3Order3Mag
40 8 Order (3) Phase Channel 0 Ch0Order3Phase
41 9 Order (3) Phase Channel 1 Ch1Order3Phase
42 10 Order (3) Phase Channel 2 Ch2Order3Phase
43 11 Order (3) Phase Channel 3 Ch3Order3Phase
44 12 FFT Band (0) Channel 0 Ch0FFTBand0
45 13 FFT Band (0) Channel 1 Ch1FFTBand0
46 14 FFT Band (0) Channel 2 Ch2FFTBand0
47 15 FFT Band (0) Channel 3 Ch3FFTBand0
48 1 16 FFT Band (1) Channel 0 Ch0FFTBand1
49 17 FFT Band (1) Channel 1 Ch1FFTBand1
50 18 FFT Band (1) Channel 2 Ch2FFTBand1
51 19 FFT Band (1) Channel 3 Ch3FFTBand1
52 20 FFT Band (2) Channel 0 Ch0FFTBand2
53 21 FFT Band (2) Channel 1 Ch1FFTBand2
54 22 FFT Band (2) Channel 2 Ch2FFTBand2
55 23 FFT Band (2) Channel 3 Ch3FFTBand2
56 24 FFT Band (3) Channel 0 Ch0FFTBand3
57 25 FFT Band (3) Channel 1 Ch1FFTBand3
58 26 FFT Band (3) Channel 2 Ch2FFTBand3
59 27 FFT Band (3) Channel 3 Ch3FFTBand3
60 28 FFT Band (4) Channel 0 Ch0FFTBand4
61 29 FFT Band (4) Channel 1 Ch1FFTBand4
62 30 FFT Band (4) Channel 2 Ch2FFTBand4
63 31 FFT Band (4) Channel 3 Ch3FFTBand4
64 0 FFT Band (5) Channel 0 Ch0FFTBand5
65 1 FFT Band (5) Channel 1 Ch1FFTBand5
66 2 FFT Band (5) Channel 2 Ch2FFTBand5
67 3 FFT Band (5) Channel 3 Ch3FFTBand5
68 4 FFT Band (6) Channel 0 Ch0FFTBand6
69 5 FFT Band (6) Channel 1 Ch1FFTBand6
70 6 FFT Band (6) Channel 2 Ch2FFTBand6
71 7 FFT Band (6) Channel 3 Ch3FFTBand6
72 8 FFT Band (7) Channel 0 Ch0FFTBand7
73 9 FFT Band (7) Channel 1 Ch1FFTBand7
74 10 FFT Band (7) Channel 2 Ch2FFTBand7
75 11 FFT Band (7) Channel 3 Ch3FFTBand7
76 12 Not 1X Channel 0 Ch0Not1X
Index DINT Bit Descriptor Tag
