328 Rockwell Automation Publication 1444-UM001D-EN-P - June 2018
Appendix A CIP Objects
77 13 Not 1X Channel 1 Ch1Not1X
78 14 Not 1X Channel 2 Ch2Not1X
79 15 Not 1X Channel 3 Ch3Not1X
80 16 DC Channel 0 Ch0DC
81 2 17 DC Channel 1 Ch1DC
82 18 DC Channel 2 Ch2DC
83 19 DC Channel 3 Ch3DC
84 20 SMAX Mag Channels 0/1 Ch0_1SMAXMag
85 21 SMAX Mag Channels 2/3 Ch2_3SMAXMag
86 22 SMAX Phase Channels 0/1 Ch0_1SMAXPhase
87 23 SMAX Phase Channels 2/3 Ch2_3SMAXPhase
88 24 Shaft Absolute Peak-to-Peak Channels 0/1 Ch0_1ShaftAbsolutePk_Pk
89 25 Shaft Absolute Peak-to-Peak Channels 2/3 Ch2_3ShaftAbsolutePk_Pk
90 26 Speed (0) Speed0
91 27 Speed (1) Speed1
92 28 Factored Speed (0) Speed0Max
93 29 Factored Speed (1) Speed1Max
94 30 Speed (0) Maximum Speed0RateOfChange
95 31 Speed (1) Maximum Speed1RateOfChange
96 0 Speed (0) Rate of Change FactoredSpeed0
97 1 Speed (1) Rate of Change FactoredSpeed1
98 2 Differential Expansion Channels 0/1 Ch0_1DifferentialExpansion
99 3 3 Differential Expansion Channels 2/3 Ch2_3DifferentialExpansion
102 6 Rod Drop 0 Ch0RodDrop
103 7 Rod Drop 1 Ch1RodDrop
104 8 Rod Drop 2 Ch2RodDrop
105 9 Rod Drop 3 Ch3RodDrop
Index DINT Bit Descriptor Tag
