Allen-Bradley 1444-TSCX02-02RB User Manual

324 Rockwell Automation Publication 1444-UM001D-EN-P - June 2018
Appendix A CIP Objects
Discrete Data – Update Rate Trend.DiscreteUpdateMultiplier Dynamix Data Manager Object Trend Overall Update Multiplier
Dynamic Data - Ch0…3 Enable Trend.DynamicData0…3En Dynamix Data Manager Object Trend Data-Set™ Enable
Dynamic Data – Update Rate Trend.DynamicUpdateMultiplier Dynamix Data Manager Object Trend Dynamic Update Multiplier
Data-Set Definition Trend.StaticParams0…3* Dynamix Data Manager Object DWORD 0…3
Alarm Buffer – Enable Trigger Trend.AlarmTriggerSource Dynamix Data Manager Object Alarm Data Storage Trigger Source
Alarm Buffer – Trigger On Any Alarm Trend.AlarmTriggerSource Dynamix Data Manager Object Alarm Data Storage Trigger Source
Alarm Buffer – Voted Alarm Condition Trend.AlarmTriggerSource Dynamix Data Manager Object Alarm Data Storage Trigger Source
Alarm Buffer – Enable Latching Trend.AlarmLatchEn Dynamix Data Manager Object Alarm Data Storage Latching
Alarm Buffer – Post Trigger Low
Resolution for Dynamic Data
Trend.DynamicLowResoultionPost
Tri gge r
Dynamix Data Manager Object Alarm % Post Trigger for Dynamic
Data Records
Alarm Buffer – Post Trigger Low
Resolution for Discrete Data
Trend.DiscreteLowResoultionPost
Tri gge r
Dynamix Data Manager Object Alarm % Post Trigger for Low-
Resolution Overall Records
Alarm Buffer – Post Trigger High
Resolution for Discrete Data
Trend.DiscreteHighResoultionPost
Tri gge r
Dynamix Data Manager Object Alarm % Post Trigger for High-
Resolution Overall Records
Transient Page
Enable Transient Capture TransientCapture.En Dynamix Transient Data Manager
Object
Transient Data Mode Control
Disable Dynamic Capture on Start Up TransientCapture.OnStartUpDisable Dynamix Transient Data Manager
Object
Transient Data Mode Control
Disable Dynamic Capture on Coast
Down
TransientCapture.OnCoastDownDisable Dynamix Transient Data Manager
Object
Transient Data Mode Control
Enable Latching TransientCapture.LatchEn Dynamix Transient Data Manager
Object
Transient Data Mode Control
Enable Overflow TransientCapture.OverflowEn Dynamix Transient Data Manager
Object
Transient Data Mode Control
Data-Set Definition TransientCapture.DiscreteParams0…3* Dynamix Transient Data Manager
Object
DWORD 0…3
Speed Reference TransientCapture.ControlSpeedRef Dynamix Transient Data Manager
Object
Source of Speed Data
Low Speed Limit TransientCapture.LowSpeedLimit Dynamix Transient Data Manager
Object
Low Speed Threshold
High-Speed Limit TransientCapture.HighSpeedLimit Dynamix Transient Data Manager
Object
High-Speed Threshold
Start Up – Number of Buffers TransientCapture.NumStartUpBuffers Dynamix Transient Data Manager
Object
Transient Data Mode Control
Start Up – Post Start Up Sample Time TransientCapture.PostStartUpSample Time Dynamix Transient Data Manager
Object
Extra startup sample time
Start Up – Delta RPM Trigger TransientCapture.StartUpDeltaRPM Dynamix Transient Data Manager
Object
Overall Delta RPM (SU)
Start Up – Delta Time Trigger TransientCapture.StartUpDeltaTime Dynamix Transient Data Manager
Object
Overall Delta Time (SU)
Coast Down – Delta RPM Trigger TransientCapture.CoastDownDeltaRPM Dynamix Transient Data Manager
Object
Overall Delta RPM (CD)
Coast Down – Delta Time Trigger TransientCapture.CoastDownDeltaTime Dynamix Transient Data Manager
Object
Overall Delta Time (CD)
Table 83 - Parameter – Tag – Object Attribute Cross-reference (continued)
Parameter Tag Member Object Attribute
