Allen-Bradley 1444-TSCX02-02RB User Manual

Rockwell Automation Publication 1444-UM001D-EN-P - June 2018 323
CIP Objects Appendix A
Measurement Alarm – Input 2 VotedAlarm00…13.Alarm2Input Dynamix Voted Alarm Object Alarm Input 2
Measurement Alarm – Input 3 VotedAlarm00…13.Alarm3Input Dynamix Voted Alarm Object Alarm Input 3
Logic VotedAlarm00…13.LogicCondition Dynamix Voted Alarm Object Alarm Logic Configuration
Setpoint Multiplier Trigger – Control 0 VotedAlarm00…13.LogicInput0 Dynamix Voted Alarm Object Alarm Multiplier Control
VotedAlarm00…13.ControllerSPM0 Dynamix Voted Alarm Object Alarm Multiplier Control
Setpoint Multiplier Trigger – Control 1 VotedAlarm00…13.LogicInput1 Dynamix Voted Alarm Object Alarm Multiplier Control
VotedAlarm00…13.ControllerSPM1 Dynamix Voted Alarm Object Alarm Multiplier Control
Setpoint Multiplier Trigger – Delay VotedAlarm00…13.SPMHoldTime Dynamix Voted Alarm Object Alarm Multiplier ON Time
Gating Speed – Reference VotedAlarm00…13.SpeedGatingEnSource Dynamix Voted Alarm Object Speed Gating Control
Gating Speed – Condition VotedAlarm00…13.SpeedGateCondition Dynamix Voted Alarm Object Speed Gating Detection
Gating Speed – High Limit VotedAlarm00…13.HSpeedGateLimit Dynamix Voted Alarm Object Higher Speed Threshold
Gating Speed – Low Limit VotedAlarm00…13.LSpeedGateLimit Dynamix Voted Alarm Object Lower Speed Threshold
I/O Gating – Gate Control VotedAlarm00…13.LogicGateSource Dynamix Voted Alarm Object Logic gating source
I/O Control VotedAlarm00…13.LogicControlSource Dynamix Voted Alarm Object Logic control source
Relay Control – Fail-Safe Enable VotedAlarm00…13.FailSafeEn Dynamix Voted Alarm Object Alarm Type
Relay Control – Latch Enable VotedAlarm00…13.LatchEn Dynamix Voted Alarm Object Alarm Behavior
Relay Page
Main Module Relay – Enable ModuleControl.RelaySource Dynamix Module Control Object Relay Source
Main Module Relay – Voted Alarm
Number
ModuleControl.RelaySource Dynamix Module Control Object Relay Source
Main Module Relay – Alarm Status to
Activate On
ModuleControl.RelaySource Dynamix Module Control Object Relay Source
Main Module Relay – Module Fault ModuleControl.ModuleFault Dynamix Module Control Object User Local Relay Control
Main Module Relay – Tach Fault ModuleControl.TachFault Dynamix Module Control Object User Local Relay Control
Main Module Relay – Communication
Fault
ModuleControl.CommunicationFault Dynamix Module Control Object User Local Relay Control
Main Module Relay – Expansion
Module Fault
ModuleControl.ExpModuleFault Dynamix Module Control Object User Local Relay Control
Main Module Relay – Expansion Bus
Fault
ModuleControl.ExpBusFault Dynamix Module Control Object User Local Relay Control
Main Module Relay – Latch Enable ModuleControl.LatchEnabled Dynamix Module Control Object User Local Relay Control
Expansion Module Relay – Enable ExpansionRelay0…2.Relay0…3Source Dynamix Relay Module Object Relay 0…3 Source
Expansion Module Relay – Voted Alarm
Number
ExpansionRelay0…2.Relay0…3Source Dynamix Relay Module Object Relay 0…3 Source
Expansion Module Relay – Alarm
Status to Activate On
ExpansionRelay0…2.Relay0…3Source Dynamix Relay Module Object Relay 0…3 Source
Expansion Module Relay – Module
Fault
ExpansionRelay
0…2.Relay0…3TripOnModuleFault Dynamix Relay Module Object Relay 0…3 User Relay Control
Expansion Module Relay – Expansion
Bus Fault
ExpansionRelay0…2.Relay0…3TripOnExpBusFault Dynamix Relay Module Object Relay 0…3 User Relay Control
Expansion Module Relay – Latch Enable ExpansionRelay0…2.Relay0…3LatchEnabled Dynamix Relay Module Object Relay 0…3 User Relay Control
Trend Page
Discrete Data - Ch0…3 Enable Trend.DiscreteData0…3En Dynamix Data Manager Object Trend Data-Set Enable
Table 83 - Parameter – Tag – Object Attribute Cross-reference (continued)
Parameter Tag Member Object Attribute
