Rockwell Automation Publication 1444-UM001D-EN-P - June 2018 115
Configure the 1444 Dynamic Measurement Module Chapter 3
Discrete Outputs
Parameter Values Comment
Pt0/1 - The 1444-DYN04-01RA includes two discrete opto-isolated outputs. These
provide output of selected status conditions or replication of selected
input signals. i
- Function Description
0 OFF Output is not used.
1…13 Voted Alarm Instance 1...13 Alarm
Alert Status
The status of the selected Voted
Alarm when the alarm is configured
to activate on an alert condition.
17…29 Voted Alarm Instance 1...13 Danger
Alert Status
The status of the selected Voted
Alarm when the alarm is configured
to activate on danger conditions.
33…45 Voted Alarm Instance 1...13 Fault
Alert Status
The status of the selected Voted
Alarm when the alarm is configured
to activate on a transducer fault
condition.
48…49 Local TTL Tacho 0...1 Input Replicated from the TTL signal that
is connected to the terminal pins.
50…51 Tacho Bus 0...1 Replicated from the TTL signal that
is communicated over the Local
Bus.
52…53 Tacho Bus 0...1 Fault The Local Bus Tacho status.
54…55 Pt0...1 Discrete Input Replicated from the Discrete Input.
56…59 Transducer 0...3 Fault Transducer Status.
127 Module Status Module Status.
Table 19 - Hardware Configuration
Parameter Values Comment
Channel Type: gSE
Input Tag Measurement Type Selections Comment
gSE Spike Energy (gSE) is a processing technique capable of detection of low
energy impacts. The measure is suitable for early detection of faults in
rolling element bearings or gears and detection of other periodic or
random low energy impact events.
Channel Type: Static (DC)
Input Tag Measurement Type Selections Comment
Rod Drop Rod Drop A triggered position (rod-drop) measurement that is taken at a fixed
(consistently the same) position of the rod during the stroke.
Differential Expansion Comp. Differential Exp. A/B (Axial) The measurement of shaft axial displacement using a pair of axial eddy-
current-probe monitoring a shaft collar target such that the
measurement range is optimally the sum of the ranges of the individual
probes.
Differential Expansion Ramp Differential Exp. A/B (Radial) The measurement of differential expansion with axial/radial eddy-
current-probe pair viewing concave or convex ramp shaft.
