Chapter 1 About the Dynamix 1444 Series Dynamic Measurement Module
The following parts listings conform to this hierarchical structure:
• Assembly level (of module and base, not including connectors)
– Connector level (choice of screw or spring clamp type)
– Component level (module or base as spare/replacement item)
Each main and expansion module terminal base includes one standard ribbon
cable connector. This connector is sufficient to interconnect all main and
expansion modules in a system.
Table 1 - 1444 Series Catalog Numbers
Type Module Catalog Number
Measurement modules Dynamic measurement module 1444-DYN04-01RA
Speed modules Tachometer signal conditioner expansion module 1444-TSCX02-02RB
Relay modules Relay expansion module 1444-RELX00-04RB
Analog output modules 4…20 mA expansion module 1444-AOFX00-04RB
Terminal bases Dynamic measurement module terminal base 1444-TB-A
Expansion module terminal base 1444-TB-B
Table 2 - Removable Plug Connector Sets
Module Spring Connector Screw Connector
1444-DYN04-01RA 1444-DYN-RPC-SPR-01 1444-DYN-RPC-SCW-01
1444 -TSCX02-024B 1444-TSC-RPC-SPR-01 1444-TSC-RPC-SCW-O1
1444-RELX00-04RB 1444-REL-RPC-SPR-01 1444-REL-RPC-SCW-01
1444-AOFX00-04RB 1444-AOF-RPC-SPR-01 1444-AOF-RPC-SCW-01
Terminal Base Spring Connector Screw Connector
1444-TB-A 1444-TBA-RPC-SPR-01 1444-TBA-SCW-01
1444-TB-B 1444-TBB-RPC-SPR-01 1444-TBB-SCW-01
Table 3 - 1444 Series Interconnect Cable Accessories
Catalog Number Description
1444-LBIC-04 Local bus interconnect cable (qty 4)
1444-BXC-0M3-01 Local bus extender cable, 0.3 m (11.8 in.)
1444-LBXC-1M0-01 Local bus extender cable, 1.0 m (39.4 in.)
