220 Rockwell Automation Publication 1444-UM001D-EN-P - June 2018
Chapter 8 Configure Alarms
Adaptive Multipliers
The five adaptive multipliers are alternatives to the single SPM-managed static
limit multiplier. Adaptive multipliers enable a method for the automatic
application of an alarm limit multiplier that is based on a measured attribute
(such as speed). When using adaptive multipliers, each of the multipliers is
associated with a range of whatever the control parameter is. If the value of the
control parameter is outside of the specified ranges, such that no multiplier is
applicable, then a multiplier of 1.0 is used.
Adaptive Multipliers is implemented via a dialog that is accessed from the
“Adaptive Multipliers” button on the Measurement Alarms page.
Figure 87 - Measurement Alarms Page
The “Adaptive Multipliers” button is only visible when “Apply Limits From” is
set to “Static Limits With Adaptive Multipliers”.
Figure 88 - Adaptive Multipliers Dialog
