268 Rockwell Automation Publication 1444-UM001D-EN-P - June 2018
Chapter 10 Operate the Module
Table 53 - Transient Status
Tag Description (if = 1)
Transient0CaptureStatus
Transient Buffer 0 Status
4 bit status
Value Description
0 Free Available / ready for transient event.
1 Data Ready Normal Transient completed normally, could be
overwritten by a new event.
2 Data Latched Normal Transient completed normally, buffer latched.
3 Transient In Progress RPM Delta RPM data acquisition in progress.
4 Transient In Progress Time Delta Time data acquisition in progress.
5 Data Ready Aborted Speed that is returned above/below the
initiating threshold, could be overwritten by
a new event.
6 Data Latched Aborted Speed that is returned above/below the
initiating threshold, could be overwritten by
a new event.
7 Data Ready time-out Speed that is crossed the initiating threshold
that is then timed out, could be overwritten
by a new event.
8 Data Latched time-out Speed that is crossed the initiating threshold
that is then timed out, buffer latched.
Transient1CaptureStatus
Transient Buffer 1 Status
Same as previous
Transient2CaptureStatus
Transient Buffer 2 Status
Transient3CaptureStatus
Transient Buffer 3 Status
