Chapter 10 Operate the Module
Example 5
Table 66 - 6 Defined Alert and Danger Alarms
Dynamic Alignment Static Alignment
Voted Alarm 0: Actuate on Alert, Danger Voted Alarm 0: Actuate on Danger
Voted Alarm 1: Actuate on Alert, Danger Voted Alarm 1: Actuate on Danger
Voted Alarm 2: Actuate on Alert, Danger Voted Alarm 2: Actuate on Danger
Voted Alarm 3: Actuate on Alert, Danger Voted Alarm 3: Actuate on Danger
Voted Alarm 4: Actuate on Alert, Danger Voted Alarm 4: Actuate on Danger
Voted Alarm 5: Actuate on Alert, Danger Voted Alarm 5: Actuate on Danger
Voted Alarms 6 … 12: Not enabled Voted Alarm 6: Actuate on Alert
Voted Alarm 7: Actuate on Alert
Voted Alarm 8: Actuate on Alert
Voted Alarm 9: Actuate on Alert
Voted Alarm 10: Actuate on Alert
Voted Alarm 11: Actuate on Alert
Voted Alarms 12: Not enabled
Relay 0 = Voted Alarm 0, on Danger Relay 0 = Voted Alarm 0, on Danger
Relay Assigned Output; NA = Not Allocated
Voted Alarm Instance Voted Alarm Status
Alarm
Status #
0123Voted
Alarm#
01Status to Activate
On
0 1000 0 01 2Danger
1 1000 0 10 1Alert
2 0100 1 10 1Alert
3 0100 1 01 2Danger
4 1100 2 10 1Alert
5 1100 2 01 2Danger
6 0010 3 10 1Alert
7 0010 3 01 2Danger
8 1010 4 10 1Alert
9 1010 4 01 2Danger
10 0110 5 10 1Alert
11 0110 5 01 2Danger
12 0000 NA 00 0
Voted Alarm Instance Voted Alarm Status
Alarm
Status #
0123Voted
Alarm#
01Status to Activate
On
0 1000 0 01 2Danger
1 0100 1 01 2Danger
2 1100 2 01 2Danger
3 0010 3 01 2Danger
4 1010 4 01 2Danger
5 0110 5 01 2Danger
6 1110 6 10 1Alert
7 0001 7 10 1Alert
8 1001 8 10 1Alert
9 0101 9 10 1Alert
10 1101 10 10 1Alert
11 0011 11 10 1Alert
12 0000 NA 00 0
