290 Rockwell Automation Publication 1444-UM001D-EN-P - June 2018
Chapter 10 Operate the Module
68 Ch0FFTBand6 FFT Band 6 magnitude values
69 Ch1FFTBand6
70 Ch2FFTBand6
71 Ch3FFTBand6
72 Ch0FFTBand7 FFT Band 7 magnitude values
73 Ch1FFTBand7
74 Ch2FFTBand7
75 Ch3FFTBand7
76 Ch0Not1X Not 1x values
77 Ch1Not1X
78 Ch2Not1X
79 Ch3Not1X
80 Ch0DC DC measurement values
81 Ch1DC
82 Ch2DC
83 Ch3DC
84 Ch0_1SMAXMag SMAX magnitude values
85 Ch2_3SMAXMag
86 Ch0_1SMAXPhase SMAX Phase values
87 Ch2_3SMAXPhase
88 Ch0_1Shaft Absolute Pk_Pk Shaft Absolute values
89 Ch2_3Shaft Absolute Pk_Pk
90 Speed0 Speed values
91 Speed1
92 FactoredSpeed0 Speed values
93 FactoredSpeed1
94 Speed0 max Maximum speed since last reset
The maximum speed value does not update when the tachometer is in fault. See Behavior for
more information.
95 Speed1 max
96 Speed0RateOfChange Speed rate of change per minute
97 Speed1RateOfChange
98 Ch0_1DiffExpansion Differential Expansion values
The measured expansion values are output to the same tags regardless of the selected
measurement mode - axial (complementary) or radial (ramp).
99 Ch2_3DiffExpansion
100 Reserved
101 Reserved
102 Ch0RodDrop Rod Drop values
103 Ch1RodDrop
104 Ch2RodDrop
105 Ch2RodDrop
Table 70 - Input Data Parameters (continued)
# Parameter Description
