304 Rockwell Automation Publication 1444-UM001D-EN-P - June 2018
Chapter 10 Operate the Module
Module Status
Table 76 - Module Status
Parameter Values
Configuration 0 - Out Of Box State (not configured)
The module does not have a configuration that is loaded or held in its
nonvolatile memory.
1 - Configuration that is loaded from nonvolatile memory
The module is executing the configuration that was in its nonvolatile
memory. It has not received a configuration from the controller.
2 - Configuration that is downloaded from controller
The module is executing a configuration that was downloaded from the
controller.
Expansion Bus 0 - Normal
Communications with all connected expansion modules is normal.
1 - Expansion Bus Failed
Indicates that the Link Status with one or more of the connected
expansion modules is failed.
Tachometer Expansion Module 0 - Not Detected
No tachometer signal conditioner expansion module is detected
connected to this module.
1 - Not Configured
A tachometer signal conditioner expansion module is detected but is not
configured.
2 - Configured
A tachometer signal conditioner expansion module is detected, has been
configured, and is operating.
Analog Output Expansion Module 0 - Not Detected
No analog output expansion module is detected connected to this
module.
1 - Not Configured
An analog output expansion module is detected but is not configured.
2 - Configured
An analog output expansion module is detected, has been configured,
and is operating.
Relay Expansion Module, Address 1 0 - Not Detected
No relay expansion module is detected connected to this module at
address 1
1 - Not Configured
A relay expansion module is detected at address 1 but is not configured
2 - Configured
A relay expansion module is detected at address 1, has been configured,
and is operating
Relay Expansion Module, Address 2 0 - Not Detected
No relay expansion module is detected connected to this module at
address 2
1 - Not Configured
A relay expansion module is detected at address 2 but is not configured
2 - Configured
A relay expansion module is detected at address 2, has been configured,
and is operating
Relay Expansion Module, Address 3 0 -Not Detected
No relay expansion module is detected connected to this module at
address 3
1 - Not Configured
A relay expansion module is detected at address 3 but is not configured
2 - Configured
A relay expansion module is detected at address 3, has been configured,
and is operating
