Rockwell Automation Publication 1444-UM001D-EN-P - June 2018 339
CIP Objects Appendix A
20 Get/Set NV Configuration Group 12 See structure definition
21 Get/Set NV Configuration Group 13 See structure definition
22 Get/Set NV Configuration Group 14 See structure definition
23 Get/Set NV Configuration Group 15 See structure definition
24 Get/Set NV Configuration Group 16 See structure definition
25 Get/Set NV Configuration Group 17 See structure definition
26 Get/Set NV Configuration Group 18 See structure definition
27 Get/Set NV Configuration Group 19 See structure definition
28 Get/Set NV Configuration Group 20 See structure definition
29 Get/Set NV Configuration Group 21 See structure definition
30 Get/Set NV Configuration Group 22 See structure definition
31 Get/Set NV Configuration Group 23 See structure definition
32 Get/Set NV Configuration Group 24 See structure definition
33 Get/Set NV Configuration Group 25 See structure definition
34 Get/Set NV Configuration Group 26 See structure definition
35 Get/Set NV Configuration Group 27 See structure definition
36 Get/Set NV Configuration Group 28 See structure definition
37 Get/Set NV Configuration Group 29 See structure definition
Table 87 - Class Attributes (continued)
Table 88 - Instance Attributes
Attribute ID Access
Rule
NV Name Data Type Description of Attribute Semantics of Values
1 Get - Configuration Status BYTE Defines module configuration status. 0: Out Of Box State (no configuration
loaded)
1: Configuration that is loaded from
nonvolatile memory
2: Configuration that is downloaded from
controller.
17 Get NV AOP Module Type SINT AOP definition module personality. Module Type
18 Get NV Module Type (applied) SINT Defines module personality. Module Type
25 Get NV Compliance Mode SINT 0 = None, 1=API-670. Indicates
whether the module is configured for a
critical protection application (1), or for
a general monitoring or non-critical
protection application (0).
Compliance Mode
Channel Application Types
32 Get NV AOP Channel 0 Application
Typ e
INT AOP definition - application types. Application Index
33 Get NV AOP Channel 1 Application
Typ e
INT
34 Get NV AOP Channel 2 Application
Typ e
INT
35 Get NV AOP Channel 3 Application
Typ e
INT
