Rockwell Automation Publication 1444-UM001D-EN-P - June 2018 345
CIP Objects Appendix A
Table 94 - Configuration Group 1
Source Object Source Instance Source Attribute Name Data Type
- - - CfgRevNumber DINT
---LocalAOP DINT[2]
0x39B 1 16 Time Slot 0 Minimum DAQ Time Multiplier INT
0x39B 1 17 Time Slot 1 Minimum DAQ Time Multiplier INT
0x39B 1 18 Time Slot 2 Minimum DAQ Time Multiplier INT
0x39B 1 19 Time Slot 3 Minimum DAQ Time Multiplier INT
- - - CRC/Time/Date for verifying a safety configuration DINT[3]
0x38A 1 17 AOP Module Type SINT
18 Module Type (Applied) SINT
25 Compliance Mode SINT
---Pad SINT
0x38A 1 32 Channel 0 AOP Application Type INT
33 Channel 1 AOP Application Type INT
34 Channel 2 AOP Application Type INT
35 Channel 3 AOP Application Type INT
36 Channel 0 Application Type INT
37 Channel 1 Application Type INT
38 Channel 2 Application Type INT
39 Channel 3 Application Type INT
0x38E 1 24 Transducer AC Units ENGUNITS
---Pad INT
0x38E 1 25 Transducer AC Sensitivity REAL
26 Transducer DC Units ENGUNITS
---Pad INT
0x38E 1 27 Transducer DC sensitivity REAL
28 TX Power Setup SINT
32 Transducer OK Configuration BYTE
---Pad INT
0x38E 1 33 Transducer OK High Threshold REAL
34 Transducer OK Low Threshold REAL
0x38E 2 24 Transducer AC Units ENGUNITS
Pad INT
0x38E 2 25 Transducer AC Sensitivity REAL
26 Transducer DC Units ENGUNITS
- - - Pad INT
0x38E 2 27 Transducer DC sensitivity REAL
28 TX Power Setup SINT
32 Transducer OK Configuration BYTE
- - - Pad INT
