Rockwell Automation Publication 1444-UM001D-EN-P - June 2018 355
CIP Objects Appendix A
- - - Pad INT
0x391 3 35 Rod Drop Decay Time REAL
0x391 4 16 DC Measurement Units ENGUNITS
- - - Pad INT
0x391 4 17 DC Measurement TC REAL
18 DC Measurement Offset REAL
19 DC Measurement Sense Control SINT
20 DC Measurement Type USINT
32 Rod Drop Trigger Source SINT
33 Rod Drop Trigger Angle INT
34 Rod Drop Measurement Range SINT
- - - Pad SINT
- - - Pad INT
0x391 4 35 Rod Drop Decay Time REAL
0x393 1 16 Tracking Filter Configuration BYTE
- - - Pad SINT
0x393 1 17 Order Measurement Units ENGUNITS
18 Order Measurement Scaling SINT
19 Tracking Filter Mode SINT
- - - Pad INT
0x393 1 20 Tracking Filter Definition (Tacho 0) REAL
21 Tracking Filter Definition (Tacho 1) REAL
32 Tracking Filter 0 setup REAL
33 Tracking Filter 1 setup REAL
34 Tracking Filter 2 setup REAL
35 Tracking Filter 3 setup REAL
0x393 2 16 Tracking Filter Configuration BYTE
- - - Pad SINT
0x393 2 17 Order Measurement Units ENGUNITS
18 Order Measurement Scaling SINT
19 Tracking Filter Mode SINT
- - - Pad INT
0x393 2 20 Tracking Filter Definition (Tacho 0) REAL
21 Tracking Filter Definition (Tacho 1) REAL
32 Tracking Filter 0 setup REAL
33 Tracking Filter 1 setup REAL
34 Tracking Filter 2 setup REAL
35 Tracking Filter 3 setup REAL
0x393 3 16 Tracking Filter Configuration BYTE
Table 97 - Configuration Group 4 (continued)
Source Object Source Instance Source Attribute ID Name Data Type
