368 Rockwell Automation Publication 1444-UM001D-EN-P - June 2018
Appendix A CIP Objects
- - - Pad SINT
0x39D 4 17 Current Output Measurement
Identifier
INT
0x39D 4 19 20 mA Output scaling REAL
0x39D 4 20 4 mA Output scaling REAL
0x39D 4 24 Current Output Not OK
Configuration
SINT
- - - Pad SINT
- - - Pad INT
0x398 0 16 Synchronization enable SINT
0x398 0 17 Waveform/FFT storage format BYTE
- - - Pad INT
0x398 1 16 Enable BYTE
0x398 1 17 Signal Source SINT
0x398 1 18 Number of averages SINT
- - - Pad SINT
0x398 1 19 Measurement Units ENGUNITS
0x398 1 20 Associated Tacho Source SINT
0x398 1 21 Waveform Record Length SINT
0x398 1 25 FFT Line Resolution SINT
0x398 1 26 FFT Window Function SINT
0x398 1 28 FFT Line value detection/scaling SINT
- - - Pad SINT
0x398 2 16 Enable BYTE
0x398 2 17 Signal Source SINT
0x398 2 18 Number of averages SINT
- - - Pad SINT
0x398 2 19 Measurement Units ENGUNITS
0x398 2 20 Associated Tacho Source SINT
0x398 2 21 Waveform Record Length SINT
0x398 2 25 FFT Line Resolution SINT
0x398 2 26 FFT Window Function SINT
0x398 2 28 FFT Line value detection/scaling SINT
- - - Pad SINT
0x398 3 16 Enable BYTE
0x398 3 17 Signal Source SINT
0x398 3 18 Number of averages SINT
- - - Pad SINT
0x398 3 19 Measurement Units ENGUNITS
0x398 3 20 Associated Tacho Source SINT
Table 101 - Configuration Group 19 (continued)
Source Object Source Instance Source Attribute ID Name Data Type
