Rockwell Automation Publication 1444-UM001D-EN-P - June 2018 371
CIP Objects Appendix A
- - - Pad INT
0x39D 0 15 Current Module Control BYTE
- - - Pad SINT
- - - Pad INT
0x39D 0 16 Auxiliary Link time out UINT
0x39D 1 16 Current Output Enable SINT
- - - Pad SINT
0x39D 1 17 Current Output Measurement
Identifier
INT
19 20 mA Output scaling REAL
20 4 mA Output scaling REAL
24 Current Output Not OK
Configuration
SINT
- - - Pad SINT
- - - Pad INT
0x39D 2 16 Current Output Enable SINT
- - - Pad SINT
0x39D 2 17 Current Output Measurement
Identifier
INT
19 20 mA Output scaling REAL
20 4 mA Output scaling REAL
24 Current Output Not OK
Configuration
SINT
- - - Pad SINT
- - - Pad INT
0x39D 3 16 Current Output Enable SINT
- - - Pad SINT
0x39D 3 17 Current Output Measurement
Identifier
INT
19 20 mA Output scaling REAL
20 4 mA Output scaling REAL
24 Current Output Not OK
Configuration
SINT
- - - Pad SINT
- - - Pad INT
0x39D 4 16 Current Output Enable SINT
- - - Pad SINT
0x39D 4 17 Current Output Measurement
Identifier
INT
19 20 mA Output scaling REAL
20 4 mA Output scaling REAL
24 Current Output Not OK
Configuration
SINT
Table 101 - Configuration Group 19 (continued)
