376 Rockwell Automation Publication 1444-UM001D-EN-P - June 2018
Appendix A CIP Objects
0x399 7/21 16 Channel Source SINT
17 Data Source SINT
18 Source of band frequency limits SINT
23 Tacho source for band limits SINT
19 Start frequency (Orders/Hz) REAL
20 Stop frequency (Orders/Hz) REAL
24 FFT Band magnitude - Type SINT
- - - Pad SINT
- - - Pad INT
0x399 8/22 16 Channel Source SINT
17 Data Source SINT
18 Source of band frequency limits SINT
23 Tacho source for band limits SINT
19 Start frequency (Orders/Hz) REAL
20 Stop frequency (Orders/Hz) REAL
24 FFT Band magnitude - Type SINT
- - - Pad SINT
- - - Pad INT
0x399 9/23 16 Channel Source SINT
17 Data Source SINT
18 Source of band frequency limits SINT
23 Tacho source for band limits SINT
19 Start frequency (Orders/Hz) REAL
20 Stop frequency (Orders/Hz) REAL
24 FFT Band magnitude - Type SINT
- - - Pad SINT
- - - Pad INT
0x399 10/24 16 Channel Source SINT
17 Data Source SINT
18 Source of band frequency limits SINT
23 Tacho source for band limits SINT
19 Start frequency (Orders/Hz) REAL
20 Stop frequency (Orders/Hz) REAL
24 FFT Band magnitude - Type SINT
- - - Pad SINT
- - - Pad INT
Table 102 - Configuration Groups 20 and 21 (continued)
Source Object Source Instance Source Attribute ID Name Data Type
