398 Rockwell Automation Publication 1444-UM001D-EN-P - June 2018
Appendix A CIP Objects
24 Get V Low Speed Threshold DINT Defines the speed threshold that initiates a
startup transient and identifies where a
coast-down transient stops.
RPM
Range: 1…28000
25 Get V High-Speed Threshold DINT Defines the speed threshold that initiates a
coast down transient and identifies where a
start-up transient stops.
RPM
Range: 50…29000
26 Get V Overall
Delta RPM
(SU)
INT Speed interval at which the overall transient
data records are stored.
Separate delta RPM for run up and coast
down events.
1…1000 RPM in 1 RPM steps
0: no delta RPM storage
27 Get V Overall Delta RPM (CD) INT Speed interval at which the overall transient
data records are stored.
Separate delta RPM for run up and coast
down events.
1…1000 RPM in 1 RPM steps
0: no delta RPM storage
28 Get V Overall Delta Time (SU) INT Delta time interval that triggers overall value
data storage when RPM change re mains
within delta RPM value.
s
Range: 1…3600
29 Get V Overall Delta Time (CD) INT Delta time interval that triggers overall value
data storage when RPM change re mains
within delta RPM value.
s
Range: 1…3600
30 Get V Disable Dynamic Data Storage BYTE Ability to disable dynamic data storage (if it
is not of interest).
Bit 0 for SU
Bit 1 for CD, disable.
Range: 0…3
31 Get V Extra Startup Sample Time INT Extends the time duration of a start-up
event.
s
Range: 0…32767
Transient Static Data Source Group of 4 DWORDs where each bit indicates whether that measurement is included or not.
64 Get V DWORD 0 DWORD Range: 0…4294967295
65 Get V DWORD 1 DWORD Range: 0…4294967295
66 Get V DWORD 2 DWORD Range: 0…4294967295
67 Get V DWORD 3 DWORD DWORD 3 is only partially populated with
measurements, hence the lower range.
Range: 0…1023
Table 125 - Instance Attributes (continued)
Attribute ID Access Rule NV Name Data Type Description of Attribute Semantics of Values
