Appendix A CIP Objects
08 Firmware Update A Firmware Update was successfully
processed
Byte 10 indicates which
firmware was updated
(instance number)
09...13 Not allocated
14 Redundant power supply
status
A change in the redundant power
supply status has been detected
Byte 8 is previous state and 9
the current 1 is fail, 1 is OK
15 Exp Module detection Identifies change in which expansion
modules are detected
Byte 8 is previous state and 10
the current
Bit set indicates that the
module is missing
16 Exp Module status A change in expansion module
reported status has been logged
Byte 8 is previous state and 9
the current 1 is fail, 0 is OK
17 Internal power supply
status
Internal power supply status change Bytes 8/9 are previous NetX
status bits 16...31, bytes 10/22
are the new status data
18 NetX status (other) Detected network issues Byte 8 is previous NetX status
bits 16...31, bytes 10/11 are the
new status data
19 Controller output assembly Changes in the 16-bit output assembly
control data have been detected
Bytes 8/0 are previous
controller data, bytes 10/11 are
the new controller data
20 Object service Monitoring of key-object services Byte 10 is an index indicating
the action, byte 11 is used to
distinguish between instances
21 DSP (reported) status Changes in the DSP status DWORD Bytes 8/11 are previous DSP
Status DWORD, Bytes 12/15 are
new DSP Status DWORD
22 Main transducer status Changes in the Channel/Transducer
status WORD
Bytes 8/9 are previous TX status
bits 0...15, bytes 10/11 are the
new TX status bits 0...15
23 Speed/tacho status Changes in the Speed/tacho status
Byte
Byte 8 is previous state and 10
the current
24 Relay states Relay state change Bytes 8/9 are previous relay
status bits 0...15, bytes 10/11
are the new relay status bits
0...15
25 Exp Module Exception A change in expansion module
exception codes
Bytes 8/9 are previous
exception data, bytes 10/11 are
the new exception data
26 Calibration status A change in module (channel)
calibration status
Byte 8 is previous state and 10
the current
27 DSP startup response Whether the DSP startup was judged
normal or not
Byte 3 indicates the startup
state: 0 - not responding, 1-
normal, 2- boot loader mode
detected
28 NV Configuration bad Flash Configuration Load – CRC error
detected
Bytes 8/11 are old/stored 32-bit
CRC
Bytes 12/15 are new/calculated
32-bit CRC
29 Active configuration CRC CRC of the configuration being loaded
during Program mode
Bytes 8/11 are the 32-bit CRC
Refer also notes for Event ID 28
30…33 IP addressing mode Whether dynamic, static or address
switch addressing is being used, see
notes for details.
No data bytes are used
Table 140 - System Event Types (continued)
ID Name Description Bytes 8…15 Application
