Rockwell Automation Publication 1444-UM001D-EN-P - June 2018 419
CIP Objects Appendix A
Table 150 - Instance Attributes
Attribute ID Access
Rule
NV Name Data Type Description of Attribute Semantics of Values
1 Get V Enabled Status BOOL Definition of enabled status of channel
setup.
0: Disabled
1: Enabled
(Active)
2 Get V Synchronous max RPM REAL Highest machine speed that the
synchronous configuration supports.
RPM
3 Get V Synchronous Min RPM REAL Lowest machine speed that the
synchronous configuration supports.
RPM
Configuration Group Group of nine configuration attributes.
16 Get V LP Filter -3 dB Point REAL Low Pass Filter -3 dB corner frequency
definition.
Hz
Range 10…45777
17 Get V HP Filter -3 dB Point REAL High Pass Filter -3 dB corner frequency
definition (this attribute is also the gSE HP
Filter -3 dB).
Hz
Range 0.1…39000
18 Get V Decimation INT Provides a control for specifying
decimation in the main asynchronous
processing stream.
Sampling Control
19 Get V SRD SINT SRD (Sample Rate Divider). Sampling Control
Range: 2…41
20 Get V Alternate Path Control SINT Alternate path control. 0: Asynchronous
1: Synchronous
2: Not Used
3: Asynchronous with independent -48
dB/octave LP filtering
21 Get V Synchronous Tacho Source SINT Only applicable when alternate path is set
to option 1 or 2.
1: Tacho 0
2: Tacho 1
22 Get V Synchronous Samples Per
Revolution
INT Only applicable when alternate path is set
to option 1 or 2.
4, 8, 16, 32, 64, 128
23 Get V Decimation INT Only applicable when alternate path is set
to option 3.
Range 1…255
Constraints due to attribute 24 are as
described in Sampling
Control
24 Get V Alternate LP Filter -3 dB
Point
REAL Only applicable when alternate path is set. Hz
Range 10…5087
